T = loom
N = weft insertion belts with central exchange or single belt
E = eccentric
EXP = extra heavy

Adjustable speed: 0 – 80 beats/min (depending on the weaving height)
Base tension: 8.000 kg/meter
Minimum warp tension: 100 kg/meter
Beat-up tension: 10.500 kg/meter

SUITABLE FOR WEAVING

Warp:

Material Diameter in mm
Stainless steel (Cable) 0,4 - 1
Stainless steel (monofilament) 0,3 - 1,2
Bronze 0,2 - 0,5

  • Warp density: min. 2/cm - max. 30/cm
  • Weft: both bobbin threads and straightened rods are used

Weft

Material Wire preparation Wire diameter in mm
Stainless steel (monofilament) Prespooler 0,2 - 1
Bronze Prespooler 0,2 - 0,5
Stainless steel (monofilament) Magazine 0,65 - 1,5

  • Weft density: min. 2/cm - max. 30/cm
  • Weft: both bobbin threads and straightened rods are used
  • Weaving width: nominal loom height mm. up to 9000 mm.

    • Contact us for information on MOD. T.N.E/EXP
