T = loom
N = central exchange weft insertion belts or single belt
E = eccentric
PS = super heavy

Adjustable speed: 0 – 120 beats/min (depending on the weaving height)

SUITABLE FOR WEAVING

Warp:
Materials/diameters:

  • Stainless steel (monofilament) 0.15 mm - 0.60 mm
  • Density: 4-325 mesh (pitch 25.4 mm)

Weft types

Materials/diameters:

  • Stainless steel (monofilament) 0.15 mm - 1.20 mm
  • Density: 4-250 mesh (pitch 25.4 mm)
Weaving width:
  • Nominal loom height up to 9.000 mm
Weaving height adjustment:
  • Weaving height up to 9.000 mm - minimum 1.000 mm continuously from the right side via the rapier opening adjustment
Warp tension:
  • Max. warp tension 8.500 kg/meter
  • Minimum warp tension 100 kg/meter
  • Maximum warp tension on beat-up 10.500 kg/meter

Contact us for information on MOD. T.N.E/PS
