T = loom for technical fabrics
N = guided belts with hooks for weft insertion, controlled by servomotors
E = number of eccentric groups for smiting frame control
P = heavy

  • Adjustable speed: 0 – 160 beats/min (depending on weaving width)
Weaving height:
  • Nominal loom height mm. up to 14,000 mm
  • Fabric adjustment on both sides min. 2,000 mm

SUITABLE FOR WEAVING

Warp:
Materials/Diameters:
  • Polyester – polyamide (monofilament) mm. 0.15 - 0.60
  • Density: number of threads per cm. min. 5 - max. 200
Weft types:
Materials/Diameters:
  • Polyester – polyamide (monofilament) mm. 0.15 – 0.60 mm
  • Density: number of threads per cm. min. 5 - max. 200
Warp tension:
  • Warp tension max. 3,000 kg/meter
  • Warp tension: min. 100 kg/meter
  • Warp tension in beat up: max. 4,000 kg/meter

Contact us for information on MOD. T.N.E/P
