T = loom for technical fabrics
N = guided belts with hooks for weft insertion, controlled by servomotors
E = number of eccentric groups for smiting frame control
PS = extra heavy

Adjustable speed:0 – 130 beats/min (depending on weaving width)
Weaving height: Nominal loom height up to 12,000 mm
Fabric adjustment on both sides: min. 2,000 mm

SUITABLE FOR WEAVING

Warp:
Materials/diameters:

  • Polyester – polyamide (monofilament) 0.15 mm – 1.20 mm

Density:
  • Number of threads per cm min. 5 – max. 200

Weft types:
Materials/diameters:
  • Polyester – polyamide (monofilament) 0.15 mm – 1.20 mm

Density:
  • number of threads per cm. min. 5 - max. 200

Warp tension:
  • Warp tension max. 5,500 kg/meter
  • Warp tension min. 100 kg/meter
  • Warp tension in beat-up: max. 6,500 kg/meter

Contact us for information on MOD. T.N.E/PS
